12201
D-Shackle - 19mm - 4.7T
Ensure secure and reliable lifting operations with our robust 19mm D-Shackle, engineered for a Working Load Limit (WLL) of 4.7 tonnes. Designed for the demanding conditions of Australian workplaces, this D-shackle provides a strong and dependable connection point for various rigging and lifting applications. Its durable construction and compliance with relevant Australian Standards make it an essential component for your lifting toolkit, offering peace of mind and operational efficiency.
Product Details
- High-strength D-Shackle with a nominal size of 19mm.
- Certified Working Load Limit (WLL) of 4.7 tonnes for safe operation.
- Constructed from high-grade, heat-treated steel for maximum durability and strength.
- Hot-dip galvanised finish provides superior corrosion resistance, ideal for outdoor and harsh environments.
- Features a secure screw pin closure for quick and easy attachment and removal.
- Complies with Australian Standard AS2741, ensuring adherence to rigorous safety requirements.
- Suitable for a wide range of lifting, towing, and rigging applications in industrial and construction settings.
- Designed for straight-line pulls, offering reliable performance under specified loads.
FAQs
What does the 4.7T rating mean for this D-Shackle?
The 4.7T rating refers to the Working Load Limit (WLL) of the D-Shackle. This is the maximum weight or force that the shackle is designed to safely support when lifting or rigging.
Is this D-Shackle compliant with Australian safety standards?
Yes, this D-Shackle is manufactured to comply with Australian Standard AS2741, which specifies requirements for steel shackles for lifting purposes, ensuring its suitability for use in Australian workplaces.
What type of pin does this D-Shackle use?
This D-Shackle features a screw pin, which allows for easy and quick attachment and detachment. Screw pin shackles are generally recommended for temporary or infrequent lifting applications.
Can this shackle be used for multi-directional loading?
D-shackles are primarily designed for straight-line pull applications. For applications involving multi-directional or angular loading, a bow shackle (which has a wider, rounded body) is generally recommended to prevent side loading on the pin.
How do I properly inspect a D-Shackle before use?
Before each use, inspect the shackle for any signs of damage such as cracks, bends, nicks, or excessive wear. Ensure the pin is straight, fully engaged, and not bent or damaged. Always check that the WLL is clearly legible and suitable for the intended load.
